Axial 22uH Inductor

An axial inductor is also referred to as a color ring inductor.  It is a two-terminal passive electronic component that is used for filtering, tuning, power electronics and spike suppression. Inductors are ideal to use in the previously listed applications because they have an innate ability to store energy in the form of a magnetic field as long as current is flowing through them. When the current ceases to flow, the established magnetic field collapses and re-introduces the current back into the circuit.



Color coding of the inductor



Axial-1uH-Inductor

Inductor Color coding



Specifications 22uH axial inductor

  • Inductance:- 22uH
  • Inductance: Fixed
  • Tolerance:- ± 10% (Silver band)
  • Power Rating:- ½ Watts
  • DC Current : 700 mA
  • DC resistance: 0.12 W
  • Has accurate dimensions

Dimensions of the 22uH axial inductor

Dimensions of Inductor



Package Includes

1 x Axial 22uH Inductor

    An axial inductor is also referred to as a color ring inductor.  It is a two-terminal passive electronic component that is used for filtering, tuning, power electronics and spike suppression. Inductors are ideal to use in the previously listed applications because they have an innate ability to store energy in the form of a magnetic field as long as current is flowing through them. When the current ceases to flow, the established magnetic field collapses and re-introduces the current back into the circuit.



    Color coding of the inductor



    Axial-1uH-Inductor

    Inductor Color coding



    Specifications 22uH axial inductor

    • Inductance:- 22uH
    • Inductance: Fixed
    • Tolerance:- ± 10% (Silver band)
    • Power Rating:- ½ Watts
    • DC Current : 700 mA
    • DC resistance: 0.12 W
    • Has accurate dimensions

    Dimensions of the 22uH axial inductor

    Dimensions of Inductor



    Package Includes

    1 x Axial 22uH Inductor
