EE22 16W SMPS High Frequency PCB Mount Transformer with Auxiliary Winding is a ferrite core transformer designed for switch mode power supply circuits requiring efficient high frequency power conversion. Comes with DP2545 IC Campatiblity. Built using an EE22 ferrite core, this transformer supports approximately 16 watt power handling and provides an output voltage range suitable for 11V to 16V applications. It includes an auxiliary winding for feedback control or secondary power requirements in SMPS designs, making it suitable for compact power supply circuits, battery charging systems, and embedded electronic power modules.

Features:

1. Designed for high frequency SMPS power supply circuits
2. EE22 ferrite core for efficient magnetic coupling
3. Comes with DP2545 IC Campatiblity.
4. Power handling capability up to 16 watt
5. Output voltage range suitable for 11V to 16V circuits
6. Includes auxiliary winding for feedback control
7. PCB mount design for easy circuit board installation
8. Low core loss suitable for switching power applications

Specifications:

• Product Type: High Frequency SMPS Transformer
• Core Type: EE22 Ferrite Core
• Number of Pins: 10
• Power Rating: 16W
• Output Voltage: 11V to 16V
• Winding Type: Primary Secondary Auxiliary
• Mounting Type: PCB Mount
• Package Type: Individual Pack

Applications:

• Switch mode power supply SMPS circuits
• Battery charging power supply modules
• DC power supply regulator circuits
• LED driver power supply designs
• Industrial electronic power systems
• Embedded electronic power modules

Also Check This Products:-

EE22 15W SMPS High Frequency Ferrite Transformer

Package Includes:

1 × EE22 16W-25W SMPS High Frequency PCB Mount Transformer with Auxiliary Winding
