Jiabaida (JBD) LiFePo4 19S 60.8V 100A BMS is a high-performance Battery Management System designed using the TP20S001 hardware platform for large-scale LiFePo4 battery packs. This BMS supports advanced features such as smart communication, precise cell balancing, and comprehensive protection mechanisms. With a continuous discharge capacity of 100A, it is ideal for high-load applications including solar energy storage, electric vehicles, and industrial-grade battery systems.

Jiabaida (JBD) LiFePo4 19S 60.8V 100A BMS Features:

• Advanced protection against overcharge, over-discharge, overcurrent, and short circuits
• Smart BMS functionality with UART/CAN/RS485 communication support
• Passive cell balancing for optimized pack health and longevity
• TP20S001 platform ensures reliability and accuracy
• Suitable for high-power LiFePo4-based applications

Jiabaida (JBD) LiFePo4 19S 60.8V 100A BMS Specification:

Specification	Value
Model	TP20S001
Supported Cells	19S (LiFePo4)
Nominal Voltage (V)	60.8
Charge Voltage (V)	68.4
Charge Current (A)	50
Continuous Discharge (A)	100
Balance Current (mA)	~30
Overcharge Detect Voltage (V)	3.75 ±0.05
Overcharge Release Voltage (V)	3.55 ±0.05
Over Discharge Detect Voltage (V)	2.2 ±0.1
Over Discharge Release Voltage (V)	2.5 ±0.1
Communication Interface	UART / CAN / RS485
Operating Temperature (°C)	-20 to 70
Dimensions (mm)	128 x 63 x 15



Package Includes:

1 x Jiabaida (JBD) LiFePo4 19S 60.8V 100A Battery Management System - BMS Protection Board
