The PWM to Voltage Converter Module is designed to convert a PWM signal (0–100% duty cycle) into a corresponding analog voltage output, specifically in the -10V range. This makes it ideal for applications where a microcontroller or PLC outputs a PWM signal that must be interfaced with analog input devices such as VFDs, DAC-controlled analog circuits, or industrial control systems. The module ensures accurate voltage conversion with stable performance and a compact design suited for embedded applications.

Features of PWM to Voltage 0–100% to -10V Converter Module:

1. Converts 0–100% PWM signal to corresponding analog voltage output
2. Supports negative voltage output up to 10V
3. Wide compatibility with PLCs, microcontrollers, and signal generators
4. Stable and linear output for precise analog control
5. Built-in filtering for smooth voltage signal
6. Easy to integrate with existing control systems

Specifications of PWM to Voltage 0–100% to -10V Converter Module:

• Input Signal: PWM (0–100% Duty Cycle)
• Output Voltage: 0V to -10V
• Input Voltage Range: 12V to 30V DC
• Output Accuracy: ±1%
• Frequency Range: 1KHz to 3KHz
• Operating Temperature: -20°C to +60°C

• Mounting: terminal block for input/output

Package Includes:

1 x PWM to Voltage 0–100% to -10V Converter Module
