The 3 Pin SPDT Rocker Switch 6A 250V AC is a sturdy and versatile switch designed for medium-current AC applications in electrical and electronic equipment. With its single-pole double-throw (SPDT) configuration, it allows switching between two circuits or changeover control in a single compact unit. The 3-pin design ensures flexible wiring options, making it suitable for both ON/OFF and changeover operations. Its rectangular body and snap-fit panel design make installation simple and reliable.

Features:

1. Rated for 6A at 250V AC for medium-current applications
2. SPDT (Single Pole Double Throw) configuration allows ON/ON or ON/OFF/ON operation
3. 3-pin design provides flexible wiring options
4. Compact rectangular rocker body for easy panel mounting
5. Push-on and solder terminals for quick and reliable connection
6. Durable construction ensures long service life and consistent performance

Specifications:

• Model: Rocker Switch – 3-Pin (SPDT)
• Switch Type: SPDT Rocker

• Number of Pins: 3

• Rated Voltage: 250V AC

• Rated Current: 6A

• Switch Operation: ON/OFF/ON (Changeover Type)

• Panel Cut-Out: 12.9mm × 19.2mm

• Bezel Size: 21.0mm × 15.0mm

• Terminals: Push-On and Solder Type

• Body Material: Plastic and Metal

• Operating Temperature Range: -20°C to +70°C

Package Includes:

1 × 3 Pin SPDT Rocker Switch - 6A 250V AC
