UNI-T UTL8212+ Dual-Channel Electronic Load is a dual-channel DC electronic load instrument designed for precision testing and evaluation of power supplies, batteries, adapters, and other DC power sources, offering up to 150V and 20A per channel with 2×200W total power, high-resolution measurements (1 mV/1 mA), dynamic testing up to 5 kHz, versatile load control, and reliable digital connectivity via RS232 or optional RS485 for electronics labs, R&D, production testing, and maintenance.

UNI-T UTL8212+ DATASHEET

Features:

1. Dual independent load channels for simultaneous testing
2. 150V / 20A per channel with 200W power capacity each
3. High resolution 1 mV/1 mA for precise measurement
4. High dynamic frequency up to 5 kHz
5. Wide current slew rate 0.04 A/ms ~ 0.2 A/μs
6. Compact ¼ 4U bench-friendly size
7. RS232 connectivity with optional RS485 interface

Specifications:

• Product Type: Electronic Load
• Model: UTL8212+
• Rated Voltage: 150V DC
• Rated Current: 20A per channel
• Total Power: 2×200W
• Resolution: 1 mV / 1 mA
• Dynamic Frequency: Up to 5 kHz
• Current Slew Rate: 0.04 A/ms ~ 0.2 A/μs
• Connectivity: RS232, optional RS485
• Operating Temperature: As per manufacturer specification
• Applications: Power supply testing, battery evaluation, adapter/load characterization, DC source lab testing, electronics R&D and maintenance

Package Includes:

1 × UNI-T UTL8212+ Dual-Channel Electronic Load
