WATTNINE® 24V (25.6V) 24Ah Rechargeable Lithium Battery Pack with Warranty
This 24V/25.6V 24AH rechargeable lithium-ion battery from Wattnine is designed to provide high energy Density. Built-in BMS with Voltage, Temperature, Charge, Current and Short Circuit Protection Light weight and High Power Density—Half the weight of acid battery with twice the power density
24V 24Ah Lithium Battery Features
- High energy density
- Equipped with Smart Battery Management System
- Long Cycle life
- Excellent Safety & Performance
Battery Specifications:
|
Nominal Characteristics |
|
|
Nominal Voltage /V |
25.6V |
|
Nominal capacity /Ah (25°C, 0.5C) |
24AH |
|
Power |
576W |
|
Operating Voltage Range |
16V-29.2V |
|
|
|
|
Pack Characteristics |
|
|
Design |
8S4P |
|
Cell type / Chemistry |
32650/LFP |
|
|
|
|
Mechanical Characteristics |
|
|
Weight |
5.3KG |
|
Dimension (LxWxH) |
282x155x80 mm |
|
Charging Connector |
Customized |
|
Discharging Connector |
Customized |
|
|
|
|
Charging Characteristics |
|
|
Charge voltage |
29.2V |
|
Max. Continues Charge current |
12A |
|
Charging Duration |
=120 Min |
|
|
|
|
Discharging Characteristics |
|
|
Max. Voltage |
29.2V |
|
Min. Voltage |
16V |
|
Nominal Discharge current |
12A |
|
Max. Continues Discharge current |
24A |
BMS – Battery Management System:
|
Protection |
|
Range |
Units |
||
|
Over Charge |
Trigger voltage |
3.75 |
V |
||
|
Release voltage |
3.55 |
V |
|||
|
Delay Time |
500 |
ms |
|||
|
|
|
|
|
|
|
|
Over Discharge |
Trigger voltage |
2.2 |
V |
||
|
Release voltage |
2.7 |
V |
|||
|
Delay Time |
200-400 |
ms |
|||
|
Over current |
Trigger Current |
26 |
A |
||
|
Delay Time |
200 |
ms |
|||
|
Balancing Function |
Yes |
||||
|
Short circuit |
Delay Time |
500 |
µs |
||
|
Manual reset |
Disconnect The Load |
||||
|
Thermal protection |
High Temperature |
70 |
°C |
||
|
Low Temperature |
-20 |
°C |
|||
Warranty Terms:
This battery pack comes with 3 year warranty from the date of purchase. Warranty is void if the pack/connector is physically damaged.
