Hi-Link 12V 5W Switch Power Supply Module (HLK-5M12) is designed for stable 12V output with high efficiency and reliable protection. Compact AC-DC power module Ideal for embedded systems, automation, and power supply applications.

Features:

1. Wide Input Voltage Range (100–240V AC)
2. Stable 12V Output
3. Ultra-Compact and Lightweight Design
4. Low Ripple and Low Noise
5. Overload and Short Circuit Protection
6. High Efficiency and Power Density
7. Meets UL, CE, EMC Standards
8. Low No-Load Power Consumption (<0.1W)

Specifications:

Parameter	Value
Brand	Hi-Link
Model	HLK-5M12
Product Type	Power Module
Input Voltage	100 – 240V AC
Output Voltage	12V
Output Power	5W
Continuous Output Current	600mA
Peak Output Current	1000mA
Voltage Regulation	±0.2%
Load Regulation	±0.5%
Operating Temperature	-20°C to +60°C
Storage Temperature	-40°C to +80°C
Humidity Range	5% – 95% RH
Pressure	80 – 106 kPa
Dimensions	33 × 19 × 15 mm
Weight	22g

If you're exploring similar compact AC-DC power solutions, you can also check out the Hi-Link 3.3V 5W Power Supply Module (HLK-5M03) for low-voltage applications, the Hi-Link 5V 2W Power Supply Module (HLK-2M05) for small embedded projects, the Hi-Link 5V 10W Power Supply Module (HLK-10M05B) for standard electronics setups, and the Hi-Link 24V 5W Power Supply Module (HLK-5M24) for higher voltage requirements, all offering reliable and efficient power conversion for a wide range of applications.

Package Includes:

1 x Hi-Link 12V 5W Switch Power Supply Module (HLK-5M12)
