The 144/430MHz Dual-Band UV Walkie Talkie Antenna is a compact and efficient antenna designed for dual-band VHF/UHF communication. Its high-quality copper construction ensures excellent signal transmission and durability, making it ideal for UV dual-band walkie talkies. With a small and lightweight design, it provides stable performance across wide frequency ranges, ensuring clear and reliable communication for handheld radio systems.

Features:

1. High gain of 2.15dBi (VHF) and 3.0dBi (UHF) for enhanced communication range

2. Omni-directional design ensures consistent signal coverage in all directions

3. Compact 45mm length ideal for portable walkie talkies and handheld transceivers

4. Durable copper material with SMA-J connector for secure and stable connection

Specifications:

• Model: SRH-805S

• Frequency Range (TX): 144/430/1200 MHz

• Frequency Range (RX): 120/150/300/450/800/900 MHz

• Frequency Range (VHF): 136–174 MHz

• Frequency Range (UHF): 400–520 MHz

• Impedance: 50Ω

• VSWR: ≤1.5

• Gain: 2.15 dBi (VHF) / 3.0 dBi (UHF)

• Polarization: Omni

• Connector Type: SMA-J

• Material & Color: Copper

• Mounting Type: SMA-J

• Size: L=45 mm

• Weight: 15 g

• Operating Temperature: -40°C to +85°C

Package Includes:

1 × 144/430MHz Dual-Band UV Walkie Talkie Antenna - SRH-805S
